The Layout Chassis

The Monocoque Design

F1 cars share a common chassis design. You don’t rebuild the cockpit for every race; you just change the tires and the aero package. In Pug, we use Layout Extension to achieve this. We build one master file (the chassis) and then “extend” it for individual pages.

Exploded view diagram. A transparent "Ghost Car" (Layout) serves as the base. Different colored "Body Panels" (Views) snap onto it.

The Master Chassis (`layout.pug`)

This file contains the common structure: doctype, head, scripts, and footer. It defines “slots” using the block keyword where other pages can insert their content.

//- views/layouts/main-layout.pug
doctype html
html(lang="en")
  head
    title Node F1 Racing
    link(rel="stylesheet", href="/css/style.css")
  body
    include ../partials/nav.pug

    //- The main content slot
    block content

    include ../partials/footer.pug

The View File (`extends`)

The individual view file declares which chassis it uses (extends) and then fills in the slots (block).

//- views/dashboard.pug
extends layouts/main-layout.pug

block content
  h1 Race Dashboard
  p Current Lap: 44/58

  .telemetry-box
    //- Specific content for this page
    +lapChart(laps)

Includes

If you just need to paste a chunk of code (like a navbar or footer) without complex logic, use include.

//- views/partials/nav.pug
nav
  a(href="/") Pit Lane
  a(href="/standings") Standings

[!NOTE] T.A. Watts says: include is looking for a file path relative to the current file. block is logical inheritance. Know the difference, or your chassis will fall apart on the first turn.

⏭ The Pit Stop Challenge

You have the tools. You have the engine. Now it’s time to prove you can handle the torque.

Next Lap: The Lab.
